AquaFlow™ Outdoor Smart Valve

Eliminate Costly Truck Rolls With Our Outdoor Smart Valve (SV2)

PRODUCT DETAILS

The AquaFlow™ with integrated AMI endpoint provides 2-way communication between the service location and the Aquana Cloud-based web and mobile applications, supporting either Cellular LTE-M or LoRaWAN remote connectivity.

With Aquana, there is a way to stay in your office and remotely shut off and turn on the customer’s water. Our remote-control smart valves, along with our cloud-based software, create automated workflows that save you time and money and keep your employees safe while eliminating costly truck rolls.

Features

  • 3 Positions (Open, Closed, Reduced Flow)
  • Lead-Free Stainless Steel Ball Valve With Brass Body
  • On-Valve Leak & Burst Detection
  • Flexible Cloud Connectivity
  • Integrated AMI Endpoint Supports Pulse or Encoded Output Meters

Specifications

Valve Positions
Open, Closed, Reduced-1 (1-2GPM)
Valve Body Material
Brass Body with Stainless Steel Ball
Case Material
Ultradur B4300 G2
Communication Interface
LTE-M (AT&T or Verizon), LoRaWAN (US915), Local Real-Time Control Using Aquana Mobile App (iOS/Android)
Max Operating Pressure
150psi
Operating Temperature
-22°F – 140°F (-30°C – 60°C)
Min/Max Water Temperature
Min 32.1°F (0.5°C) | Max 140°F (60°C)
Ratings/Certifications
NSF61/Leadfree, IP68
Power
3.6V C-Cell Lithium Metal Battery
Battery Life
10-15 Years (Based on Default Check-In & 2 Position Changes per Month)
Warranty
20-Year Limited Warranty (10-Year Full Replacement, 10-Year Prorated)
Meter Support
Pulse and Encoded Meters with Extended Alarms

Dimensions

Model
Valve Bore Size (in.)
Connection Size (in.)
Threads
Valve Lay Length (in.)
Height (in.)
Width (in.)
SV2 ⅝” x ½”
⅝”
¾” NPSM
M/F Swivel
2.4”
5.14”
3.72”
SV2 ¾”
¾”
1” NPSM
M/F Swivel
2.4”
5.14”
3.72”
AVS 1”
1”
1.25” NPSM
M/F Swivel
2.874”
6.30”
4.03”

Connectivity

Learn More About AquaFlow™

Download the Aquana Platform Overview and AquaFlow™ Datasheet for more details.
