AquaSense™ Indoor Smart Valve

Indoor Smart Valve for Asset Protection, Occupant Billing, and Leak Detection

PRODUCT DETAILS

The AquaSense™ smart valve with integrated AMI endpoint provides 2-way communication between the service location, the rental or condo unit, and the Aquana Cloud-based web and mobile applications. Every Smart Valve has 3 valve positions (open, closed, and reduced flow).

Features

3 Positions (Open, Closed, Reduced Flow)
Lead-Free Stainless Steel Ball Valve With Brass Body
On-Valve Leak & Burst Detection
Flexible Cloud Connectivity
Integrated AMI Endpoint Supports Pulse or Encoded Output Meters

Request a Quote

Specifications

Valve Positions	Open, Closed, Reduced
Valve Body Material	Lead-Free Stainless Steel Ball with Brass Body
Case Material	Estaloc 59300
Communication Interface	LoRaWAN (US915), Bluetooth for Local Control Using Aquana Mobile App (iOS/Android)
Max Operating Pressure	150psi
Operating Temperature	-22°F – 140°F (-30°C – 60°C)
Min/Max Water Temperature	Min 32.1°F (0.5°C) \| Max 140°F (60°C)
Ratings/Certifications	FCC/IC, NSF61/Leadfree, IP50
Power Specifications	Input: 12vDC 1A; Supplied by External Power Supply 100-240V, 50-60Hz, 0.5A Internal Power: 3.6V Lithium Metal Battery Included (Replaceable)
Warranty	10-Year Limited Warranty (5-Year Full Replacement, 5-Year Prorated)
Meter Support	Pulse and Encoded Meters, Configurable Read Interval
Weight	2.2 lbs (1kg) Depending Upon Pipe Size

Pipe Sizes

½” (DN15)

¾” (DN20)

1” (DN25)

Connectivity

Learn More About AquaSense™

Download the Aquana Platform Overview and AquaSense™ Datasheet for more details.

Aquana Platform Overview

AquaSense™ Datasheet
