Heartbeat Detector®
Features
- Identify the location of hidden people in vehicles
- Accurate analytics developed by Oak Ridge National Lab
- Portable, lightweight device
- Quick results provided in less than a minute
- Proven by customers worldwide since 1996
- Affordable monthly subscription plans with no upfront costs
- Real-time access to field tests as they occur
PRODUCT DETAILS
The Heartbeat Detector® is an advanced enclosed space detection system developed by the United States Department of Energy and Oak Ridge National Lab to provide quick, accurate, easy, and portable human presence detection in vehicles of any size, including fully loaded tractor-trailers.
By sensing heartbeat vibrations, the system can identify live individuals even when concealed, motionless, or hidden within confined spaces—making it a powerful solution for security, inspection, and screening applications.
Standard Package
Includes:- Heartbeat Processing Unit
- Geophone Sensors (4)
- Rugged Sensor Cabling
- Scan App
- Admin Portal
- Technical Support
- Hardware Warranty & Replacement
- Power Supply & Accessories
- User Documentation
Add-Ons
Optional Accessories:- Tablet (Windows 11)
- Starlink Connection
- Rugged Field Case
- Portable Battery Charger
Visit GSA Advantage | Contract# GS-02F-0172Y | Product# 461-06360-01
Informational Videos
HOW IT WORKS
1. Driver turns off engine and exits vehicle
2. Place sensors on the vehicle and start software
3. Software listens for 10 seconds
4. Clear Search or Pass result
5. For highest sensitivity, vehicle should be shielded from wind or rain
Heartbeat Detector® Vehicle Screening Demonstration
Learn how the Heartbeat Detector® delivers simple, rapid information to improve your perimeter security.
Watch this short video to see the solution in action.
Through a single-screen interface, administrators monitor all testing activity.
Trust but Verify with Checkpoint Live™
Checkpoint Live™ is a new remote monitoring feature in the Heartbeat Detector that gives security leaders real-time visibility into vehicle screening operations from virtually anywhere.
Through the Heartbeat Detector portal, authorized administrators monitor tests as they happen across individual or multiple screening locations. Supervisors and lead agents can oversee remote checkpoints, verify that personnel follow established screening procedures and review test results without traveling to each location.
Checkpoint Live also delivers configurable SMS alerts for designated test results. Administrators select which results require attention and identify personnel who should receive notifications. The system then flags priority results and alerts the appropriate personnel, reducing the need for supervisors to continuously watch screening activity while keeping them connected to events that warrant attention.
Articles, News & Insights
The Science Behind Heartbeat Detector®
Decades of Research, Testing, and Security Applications A person concealed inside a vehicle may be...
Building a Layered Vehicle Inspection Strategy Without Overbuilding the Checkpoint
Building a Layered Vehicle Inspection Strategy Without Overbuilding the Checkpoint Vehicle...
Vehicle Inspection System Cost
Does Every Security Upgrade Need to Be a Capital Project? Improving vehicle security can quickly...
Physical Specifications
|
Operating & Storage Temperature
|
–40 to +75° C (–40 to +212° F)
|
|
Black Box Hardware
|
8.25” x 6.5” x 2.5”
3.15lb (1.43kg)
Extruded aluminum enclosure with machined end caps
Amphenol 11 pin female military-spec connector for Cable Set Powered USB-C port |
|
Sensor Set
|
Portable sensors with 20 feet of cable each (6.09 meters) Includes four (4) waterproof polyester connectors (waterproof test 50 PSI) |
|
Cable Set
|
Quad cable set with four (4) waterproof polyester connectors: 2 – 2 conductor cables (one 50ft – 15.24m) (one 25ft – 7.62m) 11 pin male connector |
Resources
Success Stories
25 Years — our Reputation Speaks for Itself
- US Army Disciplinary Barracks
- Cheyenne Mountain NORAD
- Fleury Merogis Penitentiary
- EDF Nuclear Facilities
- US Air Force Ramstein
- US Air Force Aviano
- Ukraine Prison Service
- Lithuania Border Police
- Slovenia Border Police
- Port of Tanger
- Texas Department of Corrections
- New York Department of Corrections
- Tennessee Department of Corrections
- Kansas Department of Corrections
- Missouri Department of Corrections
- Florida Department of Corrections
- Indiana Department of Corrections
- German Prison Service
- Czech Prison Service
- Hong Kong Prison Service
- USA Federal Bureau of Prisons
- Spanish National Police
- Guardia Civil Spain
- French Ministry of Justice
- Hellenic Police
- Washington State Department of Corrections
