SENSORS

GS-1 3C SEISMONITOR

GS-1 3C Seismonitor

PRODUCT DETAILS

The 3C SeisMonitor is specially designed for three-component low-frequency, seismological monitoring. Three GS-1, 1.0 Hz geophones are orthogonally arranged (one vertical, and two horizontal) in a convenient, sealed carrying case with handle, input connector, and leveling bubble.

FEATURES

  • Portable, non-clamping, 3 component, low frequency SeisMonitor in a convenient carry case.
  • Device is environmentally rated IP67
  • The SeisMonitor is ideally suited for seismological, engineering, and scientific applications where passive, low noise, short period, tri-axial sensors are required.
GS-1 3C SeisMonitor@2x

PHYSICAL SPECIFICATIONS

Operating & Storage Temperature –40 to +100° C (–40 to +212° F)
Operational Range Vertical to 7.5° Horizontal to 0.5°
Portable Case Aluminum
Double O-ring sealed top and bottom
Carrying handle
Leveling bubble built into top

ELECTRICAL SPECIFICATIONS

Sensor Type GS-1 Seismometer
Triaxial Orientation Orthogonal
Natural Frequency 1.0 Hz
DC Resistance Options 450Ω, 4550Ω, 17400Ω
Sensitivity Options See GS-1 specifications
Extended Bandwidth up to 100 Hz
